Hastelloy C22 Pipe & Tube

Hastelloy C22 Pipe & Tube

Metal Yard is a recognized stockist of Hastelloy C22 Tubes & Pipes, which must not be used in service temp exceeding 1250 Degree F because of the formation of damaging stages that form beyond this temp. Although ductile enough to be formed by cold working, intermediate annealing in Hastelloy C22 Pipes may be necessary due to work hardening. Hastelloy C22 Seamless Pipes is much more resistant to this form of attack than the comparative, austenitic stainless steels. Some of the area of present or potential use for Hastelloy C22 Seamless Tubes is: Acetic acid/Acetic Anhydride, cellophane manufacturing, chlorine spargers, chlorination systems, circuit board etching equipment, complex acid/chemical mixtures, fans and blowers. Wrought methods of Hastelloy C22 Welded Pipes are equipped in the solution heat preserved form if otherwise stated. However, Nitrogen gas in this Alloy C22 Pipes can be substituted for hydrogen gases, but the cut quality will deteriorate slightly. Hastelloy C22 Welded Tubes is covered by ASME Section VIII, Division I, where forging should be performed in the range of 1750 - 2050 Degree F followed by rapid cooling.

Hastelloy C-22 EFW Pipes has exceptional resistance to a wide variety of chemical process environments, including strong oxidizers such as cupric and ferric chlorides, chlorine, hot contaminated solutions like (inorganic and organic), acetic anhydride and acetic acids, formic, and seawater and brine solutions. Hastelloy C-22 ERW Pipes also offers optimum resistance to environments where reducing and oxidizing conditions are encountered in process streams.

Specifications

ASTM, ASME and API

Specifications : ASTM, ASME B622, B619, B622, B626, B575, B574, B564,B366

Size : 15NB TO 150 NB IN

Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS

Length : Single Random, Double Random & Required Length

Types : Seamless / ERW / Welded / Fabricated / CDW

Form : Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes

End : Plain End, Beveled End, Treaded

C22 Hastelloy Pipes & Tubes Equivalent Grades
STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Hastelloy C22 2.4602 N06022 NW 6022 - - - NiCr21Mo14W -
Hastelloy C22 Pipes & Tubes Chemical Composition
Grade C Mn Si Co S Ni Cr Fe Mo W V P
Hastelloy C22 0.010 max 0.50 max 0.08 max 2.5 max 0.02 max Bal 20 – 22.5 2 – 6 12.5 – 14.5 2.5 – 3.5 0.35 max 0.02 max
Hastelloy C22 Pipes & Tubes Mechanical & Physical Properties
Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Hastelloy C22 8.69 g/cm3 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 Psi – 45000 , MPa – 310 45 %
