Duplex S31803 / 2205 Sheets, Plates, Coils

Duplex Steel S31803 / 2205 Sheets, Plates, Coils

The metal yard is an esteemed firm, engaged in providing wide varieties of DUPLEX STEEL- S31803, 2205 PLATES, offers same at most economical prices. These plates are high alloy plates means having exceptional corrosion resistant property. Its have formability property helps to construct designs easily with simple machines at low machining costs. Plates are completely designed for wearing heavy jerks that can be used for fabricating machine components. The features of opposing stress rupture and cracks compile these plates safest option for engineering purposes. These plates work in terms of elevated temperatures so that these are used in constructing the body of heaters and boilers.

Specifications These are manufactured by cold or hot rolling process, various hardening process is done with strengthened plates. The heat treatment process abolishes chances of manufacturing defects on plates. They have Finishes by matte, BA, hairline, No 1, Brush, sandblasting or bright black polish. ASTM A240/ ASME SA240 are standard of plates, UNS NO S31803, UNS NO S2205 are the material grade of these category plates. Thickness 4 mm to 100 mm, width 1000 mm to 3500 mm, length 2000 mm to 6000 mm and other custom sizes. Flat, strip, roll, plain, shim is some shapes of plates.

Metal yard offer DUPLEX STEEL- S31803 / 2205 SHEETS, PLATES at low expense. They use tested raw materials for processing plates. Radiographic test, positive material test, intergranular corrosion test, flattening test, flaring test are done on plates and later manufactured plates are examined by third parties for quality assurance so that none of the damaged plates reach to your doorstep.

ASTM A240 Duplex Steel S31803 / 2205 Sheets, Plates, Coils Specification

Specifications : ASTM A240 / ASME SA240

Item : Duplex Steel Coils (Hot rolled, cold rolled)

Standard : JIS, AISI, ASTM, GB, DIN, EN, etc

Surface : the surface and finish of Duplex Steel Coils: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc

Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc

Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc

Manufacturer : POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu

Thickness : 0.3~10.0mm

Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)

End : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)

Grades : S31803 / 2205

Duplex Steel S31803 / 2205 Sheets, Plates, Coils Equivalent Grades
Duplex 2205 S31803 1.4462
Duplex 2205 Sheet, Plate, Coil Chemical Composition
Grade C Mn Si P S Cr Mo Ni N Fe
Duplex S31803 .030 Max 2.00 Max 1.00 Max .030 Max .020 Max 22.0-23.0 3.00-3.50 4.50-6.50 0.14-0.20 Balance
S31803 / 2205 Duplex Plates, Sheets, Coils Mechanical & Physical Properties
Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
7.8 g/cm3 1350 °C (2460 °F) Psi – 116000 , MPa – 800 Psi – 80000 , MPa – 550 15 %
